Stainles Steel 317L Nuts & Bolts

317L Stainless Steel Nuts , High Tensile Nut Bolt, Custom Grade & Size Available At Best Price & Free Sample

Our 317L Stainless Steel Fasteners product range includes 304 Stainless Steel Bolts, Hexagon head bolt, Hexagon head screw, Round head square neck bolt, Hexagon socket head cap screw in full thread and half thread, Hexagon wood screw, Hexagon socket button head screw, Hexagon socket button flange screw, Hexagon socket counter sunk head cap screw in full thread and half thread, square nuts, square weld nuts, hexagon weld nuts, thick nyloc nuts, hexagon flange nuts, threaded rods, dowel screws,Plain / Flat Washer, Spring Washers, Countersunk Washer,Tooth Lock Washer and many more. We provide products as per DIN, ANSI, JIS standards.

The Stainless Steel Fasteners which is stocked by Calico metal are manufactured in accordance with Relevant International Standards such as DIN, ISO, ANSI OR BS standards, providing assured quality with processes, systems and procedures ISO9001:2008 approved. Calico metal is 100% percent focused on customer care with are ISO9001:2008 compliant for both in house Manufacturing while providing the best service possible to ensure customer satisfaction. We have reputed clients, an extensive and comprehensive stock range, along with competitive pricing and offer a wide range of different sized cut-lengths of all threads from stock.

A Nut and bolt is a type of fastener characterized by a helical ridge, known as an external thread or just thread, wrapped around a cylinder. Some screw threads are designed to mate with a complementary thread, known as an internal thread, often in the form of a nut or an object that has the internal thread formed into it. Other screw threads are designed to cut a helical groove in a softer material as the screw is inserted. The most common uses of screws are to hold objects together and to position objects.

317L is a molybdenum bearing, low carbon content "L" grade austenitic stainless steel that provides improved corrosion resistance over 304L and 316L stainless steels. The low carbon provides resistance to sensitization during welding and other thermal processes. 317L is non-magnetic in the annealed condition but may become slightly magnetic as a result of welding. 317L has excellent corrosion resistance in a wide range of chemicals, especially in acidic chloride environments such as those encountered in pulp and paper mills. Increased levels of chromium, nickel and molybdenum compared to 316L stainless steel improve resistance to chloride pitting and general corrosion.

Alloy 317L is an austenitic stainless steel that combines excellent high temperature properties with good ductility and weldability. It is typically used for elevated temperature applications as its high chromium and nickel content provide solid corrosion resistance, excellent resistance to oxidation, and superior strength in temperatures up to 2100°F. Due to its high chromium and nickel content, it is superior to 310 or 310S stainless in most environments.

Applications

  • Flue-gas desulfurization systems
  • Chemical process vessels
  • Petrochemical
  • Pulp and Paper
  • Condensers in power generation

Chemical Composition

SS
317
317L
Ni
11 - 14
11 - 15
N
-
-
Cr
18 – 20
18 - 20
C
0.08 max
0.035 max
Si
1 max
1 max
Mn
2 max
2 max
P
0.040 max
0.040 max
S
0.030 max
0.03 max
Mo
3.00 - 4.00
3 – 4

Mechanical Properties

Density
8.0 g/cm3
Melting Point
1454 °C (2650 °F)
Tensile Strength
Psi – 75000 , MPa – 515
Yield Strength (0.2%Offset)
Psi – 30000 , MPa – 205
Elongation
35 %

Physical Properties

Specific Heat (0-100°C)
Thermal Conductivity
Thermal Expansion
Modulus Elasticity
Electrical Resistivity
Density
500
14.6
16.5
193
7.4
7.99
J.kg-1.°K-1
W.m -1.°K-1
mm/m/°C
GPa
μohm/cm
g/cm3

Calico Metal Ind Pvt Ltd exports their products to countries like UAE, Bahrain, Italy, Indonesia, Malaysia, United States, Mexico, Chine, Brazil, Peru, Nigeria, Kuwait, Jordan, Dubai, Thailand (Bangkok), Venezuela, Iran, Germany, UK, Canada, Russia, Turkey, Australia, New Zealand, Sri Lanka, Vietnam, South Africa, Kazakhstan & Saudi Arabia.
