Duplex Steel 2304 Plate Supplier Manufacturer

Duplex Alloy 2304 can be cold rolled to various tempers. Contact Ulbrich Technical Service for additional information.

Duplex 2304 contains 23% chrome, 4% nickel and molybdenum-free duplex stainless steel with a ferritic and austenitic balance of structure. It has general resistance to corrosion similar or better than 304L and 316L alloys, but yields almost twice that of austenitic stainless steel. Duplex 2304 can also demonstrate improved stress-corrosion resistant properties compared with 304 and 316 thanks to its duplex microstructure and low nickel and high chromium content.It is usually suitable for all the applications in the temperature range from -58 F to 572 F, and has been designed with high mechanical strength, good corrosion resistance, good machining resistance, low thermal expansion, high thermal strength, good thermal conductivity and manufacturing. It is ideal for all applications.Duplex 2304 plates are made from duplex stainless steel and are structured in a balance between ferritic and austenitic. It is highly resistant to stress corrosion, has high thermal conductivity, low thermal expansion and easy manufacturing. This steel is not recommended in areas where the steel would be exposed for longer durations to temperatures above 1058 ° C (570 ° F).

Characteristics

  • High resistance to chloride stress corrosion cracking
  • Resistance to chloride pitting and crevice corrosion
  • Good general corrosion resistance
  • Good sulfide stress corrosion resistance
  • High Strength
  • Good weldability and workability

Applications

  • Chloride containing environments
  • Welded pipe systems within the Pulp and Paper, Chemical and Petrochemical, and Water Treatment industries
  • Transportations
  • Heat exchanger tubes
  • Architecture, building, construction

Chemical Composition

Element Content (%)
Iron, Fe 72.679
Chromium, Cr 23
Nickel, Ni 4
Molybdenum, Mo 0.20
Nitrogen, N 0.1
Carbon, C 0.02
Sulfur, S 0.001

Mechanical Properties

Properties Metric Imperial
Tensile strength ≥ 600 MPa ≥ 87000 psi
Yield strength (@strain 0.200 %) ≥ 400 MPa ≥ 58000 psi
Modulus of elasticity 200 GPa 29000 ksi
Shear modulus (@temperature 20°C/ 68°F) 75.0 GPa 10900 ksi
Poisson’s ratio 0.333 0.333
Elongation at break ≥ 25 % ≥ 25 %
Hardness, Rockwell C ≤ 20.0 ≤ 20.0
Hardness, Brinell 180 - 230 180 - 230
