Duplex 2205 Strips

Duplex Steel 2205 Hot Rolled Strips, Duplex Steel 2205 Galvanized Strips,Duplex 2205 Strips, WERKSTOFF NR. 1.4462 Strips, ASTM A240 Duplex Steel 2205 Strips, Duplex Steel 2205 Strips Exporter

We are one of the leading in manufacturing and supplying of Duplex Steel 2205 Strips. We are producing in various Duplex Steel 2205 like a different size, Shapes, and Dimension And we also produce in custom size as per client requirement. It is manufactured by using of premium quality of raw material and latest technology and machinery. Duplex Steel 2205 Strip contains Ferrite content up to 63.54%., Chromium content up to 23 % and Nickel content up to 6.50%. Duplex Steel 2205 Polish Strips has the best corrosion resistance properties. Duplex 2205 alloy can be heated to harden further. It can be heat worked at a temperature of 1750 degree F to 2250 Degree F. Duplex 2205 alloy has the best corrosion resistance to stress corrosion cracking. Duplex 2205 is a ferritic and austenitic steel alloy—duplex steel 2205 Consists of high toughness and best welding properties. Duplex 2205 strip has the best corrosion resistance to pitting and crevice corrosion. It possesses high tensile strength and yield strength properties—molybdenum and Nickel alloy in the purest form, which shows excellent corrosion.

Standard Specification of Duplex Steel 2205 Strips is ASTM A240 / ASME SA240. Standard is JIS, AISI, ASTM, GB, DIN, EN, etc. Width is 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3500mm,etc. Thickness Is 0.3mm to 120mm. Chemical Composition of Duplex Steel 2205 Strips is as follows like Carbon is 0.030max, Manganese is 2.00max. Silicon is 1.00 max. Phosphorus is 0.030 max. Sulfur is 0.020 max. Chromium is 21.0-23.0max. Molybdenum is 2.50-3.50, And Nickel is 4.50-6.50. It also contains Mechanical properties such as Density content up to 7.8g/cm3. Melting point content up to 1350 degree C.Tensile strength Content up to PSi-116000 Mps- 800. etc.

We are manufacturing Duplex 2205 strips in a high-tech manufacturing unit, and professional workers maintain product quality. So, we supply premium quality Duplex Steel 2205 strip to our client. After the production, we do packaging of products as per Standard packaging. It is safe and does ensure free damage products.

Duplex Steel 2205 Strips Exporter,Duplex Steel 2205 Polish Strips, Duplex Steel 2205 Strips Supplier in Mumbai,ASTM A240 Duplex Steel 2205 Strips, DIN 1.4462 Export Quality Strips, Duplex Steel 2205 Strip Coils, 2205 Duplex Steel 2b finish Strips

Characteristics

  • High resistance to chloride stress corrosion cracking
  • Resistance to chloride pitting and crevice corrosion
  • Good general corrosion resistance
  • Good sulfide stress corrosion resistance
  • High Strength
  • Good weldability and workability

Applications

  • Chemical process vessels, piping and heat exchangers
  • Pulp mill digesters, bleach washers, chip pre-steaming vessels
  • Food processing equipment
  • Oil field piping and heat exchangers
  • Flue gas desulfurization equipment

Chemical Composition

Grade



C

Mn

Si

P

S

Cr

Mo

Ni

N

2205 (S31803)

Min

Max

-

0.030

-

2.00

-

1.00

-

0.030

-

0.020

21.0

23.0

2.5

3.5

4.5

6.5

0.08

0.20

2205 (S32205)

Min

Max

-

0.030

-

2.00

-

1.00

-

0.030

-

0.020

22.0

23.0

3.0

3.5

4.5

6.5

0.14

0.20

Mechanical Properties

Grade

Tensile Str
(MPa) min

Yield Strength
0.2% Proof
(MPa) min

Elongation
(% in 50mm) min

Hardness

Rockwell C (HR C)

Brinell (HB)

2205

621

448

25

31 max

293 max

Physical Properties

Physical propertyValue
Density: 0.278 lb/in3
Melting Range:2525-2630°F

Specific Heat Capacity at 212°F

0.119 Btu/lb/°F

Thermal Conductivity at 212°F

8.4 Btu/hr-ft-°F

Poisson's Ratio

0.3

Elastic Modulus at 72°F

29 x 10 psi

Size Chart

Stocked Sizes
Size (in inches)
Size (in mm)
.125"
3.18mm
.134"
3.40mm
.156"
3.96mm
.187"
4.75mm
.250"
6.35mm
.312"
7.92mm
.375"
9.53mm
.500"
12.7mm
.625"
15.9mm
.750"
19.1mm
.875"
22.2mm
1"
25.4mm
1.125"
28.6mm
1.250"
31.8mm
1.500"
38.1mm
1.750"
44.5mm
2"
50.8mm
2.500"
63.5mm
3"
76.2mm

Equivalent Grades - duplex 2205

STANDARD
WERKSTOFF NR.
UNS
Duplex 2205 Plate
1.4462 / 1.4462

UNS S31803 / UNS S32205


We Export:

Calico Metal Ind Pvt Ltd exports their products to countries like UAE, Bahrain, Italy, Indonesia, Malaysia, United States, Mexico, Chine, Brazil, Peru, Nigeria, Kuwait, Jordan, Dubai, Thailand (Bangkok), Venezuela, Iran, Germany, UK, Canada, Russia, Turkey, Australia, New Zealand, Sri Lanka, Vietnam, South Africa, Kazakhstan & Saudi Arabia.
