Duplex Steel UNS S31803 Coils

Duplex S31803 Coils, Duplex SAF S31803 Coils, Duplex Steel S31803 Coils Stockist, 1.4462 Coils, Duplex Steel UNS S31803 Coils, S31803 Duplex Steel Cold Rolled Coils, Duplex Stainless Steel S31803 Coils, Duplex Steel UNS S31803 Coils, Duplex Steel S31803 HR Coils

Calicometal is a reputed fabricator and exporter of superior quality of Duplex Steel UNS S31083 Coils. Duplex Steel UNS S31803 Coils contain high Chromium, Nitrogen, nickel, and Molybdenum. It provides excellent corrosion resistance in extreme environments. We are offering Duplex steel UNS S31803 Coils in several Sizes, Dimensions, and thickness. We also offer these strips in customized as per the requirement of our client. These Duplex steel provide high yield strength and excellent resistance to general corrosion. We are providing Duplex steel UNS S31803 coils with many useful specifications and advantages. Some are high tensile strength and excellent ant - obstructive, rugged structure, perfect dimensional accuracy, and long working life. These SAF S31803 Duplex Steel CR Coils are offer superior resistance to the pitting, Crevice, and stress corrosion cracking. We strictly examine and test the raw material before using it for the fabrication process. Our experts follow international manufacturing norms and guidelines for the development of premium quality of Duplex S31803 Industrial Coils as per our customers' demands. Our all professional workers are monitoring the product at every stage of production. So, our product quality is the best.

Standard Specification of Duplex S31803 Coils is ASTM A240/ ASME SA240. Dimension is ASTM, ASME, and API of Duplex steel UNS S31083. Size is 1000mm, 1219mm, 1500mm and 2000mm. Thickness is 4mm - 100mm. Calicometal uses the latest technology, Methodology, and Standard guidelines to develop Duplex steel UNS S31803 Coils. We exactly design these Coils according to the international standard and specifications. Our quality checking team checks the quality of the Strips to assure excellent efficiency. They check every essential Parameter as per the guidelines of international quality standards. These tests include the Hardness test, Chemical test, Pitting resistant test, Mechanical Test and Positive material identification test, etc. We are supplying superior quality of Duplex Steel UNS S31803 Coils.

ASTM A240 S31803 Duplex Steel Coils, Duplex Steel S31803 Coils at Best Price, ASME SA 240 Duplex S31803 Coils, Duplex 3S31803 #8 Finish Coils, Duplex S31803 Industrial Coils Exporter in India, Duplex S31803 Hot Rolled Coils, 2B Finish Duplex S31803 Coils, SAF S31803 Duplex Steel CR Coils.

Characteristics

  • High resistance to chloride stress corrosion cracking
  • Resistance to chloride pitting and crevice corrosion
  • Good general corrosion resistance
  • Good sulfide stress corrosion resistance
  • High Strength
  • Good weldability and workability

Applications

  • Chemical process vessels, piping and heat exchangers
  • Pulp mill digesters, bleach washers, chip pre-steaming vessels
  • Food processing equipment
  • Oil field piping and heat exchangers
  • Flue gas desulfurization equipment

Chemical Composition

Grade



C

Mn

Si

P

S

Cr

Mo

Ni

N

2205 (S31803)

Min

Max

-

0.030

-

2.00

-

1.00

-

0.030

-

0.020

21.0

23.0

2.5

3.5

4.5

6.5

0.08

0.20

2205 (S32205)

Min

Max

-

0.030

-

2.00

-

1.00

-

0.030

-

0.020

22.0

23.0

3.0

3.5

4.5

6.5

0.14

0.20

Mechanical Properties

Grade

Tensile Str
(MPa) min

Yield Strength
0.2% Proof
(MPa) min

Elongation
(% in 50mm) min

Hardness

Rockwell C (HR C)

Brinell (HB)

2205

621

448

25

31 max

293 max

Physical Properties

Physical propertyValue
Density: 0.278 lb/in3
Melting Range:2525-2630°F

Specific Heat Capacity at 212°F

0.119 Btu/lb/°F

Thermal Conductivity at 212°F

8.4 Btu/hr-ft-°F

Poisson's Ratio

0.3

Elastic Modulus at 72°F

29 x 10 psi

Size Chart

Stocked Sizes
Size (in inches)
Size (in mm)
.125"
3.18mm
.134"
3.40mm
.156"
3.96mm
.187"
4.75mm
.250"
6.35mm
.312"
7.92mm
.375"
9.53mm
.500"
12.7mm
.625"
15.9mm
.750"
19.1mm
.875"
22.2mm
1"
25.4mm
1.125"
28.6mm
1.250"
31.8mm
1.500"
38.1mm
1.750"
44.5mm
2"
50.8mm
2.500"
63.5mm
3"
76.2mm

Equivalent Grades - duplex 2205

STANDARD
WERKSTOFF NR.
UNS
Duplex 2205 Plate
1.4462 / 1.4462

UNS S31803 / UNS S32205
