Duplex 2205 Shim Sheets

Duplex Steel 2205 Shim Sheets, Duplex Stainless Steel Shim Sheets, ASTM A240 Duplex Steel 2205 Shim Sheets, Duplex 2205 Shim Sheets, Duplex Steel 1.4462 Shim Sheets.

Calicometal Is one of the prominent companies in Manufacturing and exporting Duplex Steel 2205 Shims. We are producing Duplex steel 2205 Shims in various Sizes, Shapes, and Dimensions, and also we make custom design as per the demand of our client. We use high-quality raw material and the latest technology and Methodology under the supervision of professional industry workers. We produce these Shims and supply them at the global level. Duplex Steel 2205 Shims offers excellent resistance to corrosion and very high mechanical strength. Duplex steel 2205 Shims have very high resistance to chloride corrosion, combined with very high mechanical strength. And it is particularly suited for use in aggressive acidic, chloride-containing environments. Duplex Steel 2205 Plain Sheets are used for service in a highly corrosive condition where very high mechanical strength is required. Some are high tensile strength and excellent anti -resistant, rugged structure and perfect dimension accuracy and long life service. Duplex steel 2205 Shims contain high molybdenum, Chromium, and nitrogen content, which offer outstanding resistance to pitting and crevice corrosion. These shim sheets are developed to be used in highly corrosive environments. Duplex steel is used in various application industries like Chemical. Pharmaceutical, oil, and gas industries. Fats, fertilizers and Sugar mills & Distilleries, Paint, Paper and pulp industries, etc.

What is duplex 2205 Shim Sheets?

Duplex steel 2205 Shims has many properties like high resistance to pitting, high strength, stress corrosion, crevice corrosion, and cracking resistance. Duplex steel shim provides superior welding and high mechanical strength properties. Our high-tech manufacturing unit referring to international guidelines, and professional workers manufacture all these shims as per national and international quality standards. These best quality of Duplex 2205 shims is prominent due to their features and standard specification, Compact design. Before dispatching our client's products, we ensure that we do a quality test of all the products. There is a various test like the Hardness test, Chemical analysis, and Resistance test, etc. These certificates provide to our clients. After that, we do dispatch the products with proper packaging.

Duplex Steel 2205 Cold Rolled Sheets, Duplex Steel 2205 Hot Rolled Sheets, Duplex Steel S32205 Shim Sheets, Duplex Steel 2205 Plain Sheets, Duplex Steel 2205 Hair Line Finish Sheets, Duplex Steel 2205 Sandblast Finish Sheets.


Duplex 2205 Shim Sheets

Characteristics

  • High resistance to chloride stress corrosion cracking
  • Resistance to chloride pitting and crevice corrosion
  • Good general corrosion resistance
  • Good sulfide stress corrosion resistance
  • High Strength
  • Good weldability and workability

Applications

  • Chemical process vessels, piping and heat exchangers
  • Pulp mill digesters, bleach washers, chip pre-steaming vessels
  • Food processing equipment
  • Oil field piping and heat exchangers
  • Flue gas desulfurization equipment

Also see

Duplex Steel 2205 Coil

Duplex 2205 Shim Sheet
Duplex Steel 2205 Strip

ASTM A240 Duplex 2205 Shim
Duplex Steel 2205 Sheet.

UNS S32205 Shim Sheet


Specification Of Duplex 2205 Shim Sheet


Standards : ASTM A240 / ASME SA240

Hardness : Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc.

Width : 14' (355 MM) to 2' (610 MM)

Thickness : 0.05 MM thickness, 0.10 MM, 0.15 MM, 0.20 MM, 0.25 MM, 0. 30 MM, 0. 35 MM, 0.40 MM

Form : Decorative Round Hole, Dimpled, Square Holes, Gold Mirror Round Hole, Round Punch, Etched, Colored Shim Sheets.

Finish : 2B, BA


Equivalent Grades - Duplex 2205 Shim Sheet

STANDARD
WERKSTOFF NR.
UNS

Duplex 2205 Plate
1.4462 / 1.4462
UNS S31803 / UNS S32205

Chemical Composition of Duplex 2205 Shim Sheet

Grade



C

Mn

Si

P

S

Cr

Mo

Ni

N

2205 (S31803)

Min

Max

-

0.030

-

2.00

-

1.00

-

0.030

-

0.020

21.0

23.0

2.5

3.5

4.5

6.5

0.08

0.20

2205 (S32205)

Min

Max

-

0.030

-

2.00

-

1.00

-

0.030

-

0.020

22.0

23.0

3.0

3.5

4.5

6.5

0.14

0.20

Mechanical Properties of Duplex 2205 Shim Sheet

Grade

Tensile Str
(MPa) min

Yield Strength
0.2% Proof
(MPa) min

Elongation
(% in 50mm) min

Hardness

Rockwell C (HR C)

Brinell (HB)

2205

621

448

25

31 max

293 max

Physical Properties of Duplex 2205 Shim Sheet

Physical Property

Value

Density: 0.278 lb/in3
Melting Range:2525-2630°F

Specific Heat Capacity at 212°F

0.119 Btu/lb/°F

Thermal Conductivity at 212°F

8.4 Btu/hr-ft-°F

Poisson's Ratio

0.3

Elastic Modulus at 72°F

29 x 10 psi

Size Chart

Stocked Sizes
Size (in inches)
Size (in mm)
.125"
3.18mm
.134"
3.40mm
.156"
3.96mm
.187"
4.75mm
.250"
6.35mm
.312"
7.92mm
.375"
9.53mm
.500"
12.7mm
.625"
15.9mm
.750"
19.1mm
.875"
22.2mm
1"
25.4mm
1.125"
28.6mm
1.250"
31.8mm
1.500"
38.1mm
1.750"
44.5mm
2"
50.8mm
2.500"
63.5mm
3"
76.2mm

Duplex Steel 2205 Sheet Price List

Duplex 2205 Shim Sheet

Price

ASTM A240 2205 Shim Sheet price $5-$8/kg
Duplex Steel 2205 Shim Sheet price 300- 500 Rupee/kg
2B Finish Duplex 2205 Shim Sheet price 15-20 Dirham/kg
UNS S32205 Shim Sheet Price 3- 5 pound/kg
SAF 2205 Duplex Shim Sheet Price 1-1.9 kuwaiti Dinar/kg

Notes: Prices Are Fluctuating as per Market
