ASTM A240 / ASME SA240 UNS S31803 Plate

Duplex S31803 Plate, Duplex SAF S31803 Plate, Duplex Steel S31803 Plate Stockist, 1.4462 Plate, Duplex Steel UNS S31803 Plate, S31803 Duplex Steel Cold Rolled Plate, Duplex Stainless Steel S31803 Plate, Duplex Steel UNS S31803 Plate, Duplex Steel S31803 HR Plate

ASTM A240  UNS S31803 Plates consist of equal ratios of ferrite and austenitic metals. These plates are highly made of excellent quality material and advanced technology. UNS S31803 plates are also a combination of strength ductility and malleability, and the grade combines great mechanical stability and elasticity. Duplex S31803 Plate is being used in various types of industries for a variety of purposes.

ASME SA240 UNS S31803 grade is a duplex grade with a combination of ferrite and austenitic microstructure which provides great protection from various chemical and physical resistance. The chemical composition of this grade improves its resistance to pitting, forging, and welding. The grade consists moreover 40-50% of ferrite grade that provides excellent exposure at hot and cold temperatures. The grade offers high resistance from various corrosion, crevice corrosion, and stress-cracking procedures. ASME SA240 Gr S31803 Plates are one of the most highly demanded plates in the industry today.

Chemical Composition:

The grade Duplex UNS S31803 Plate is made from high-quality materials and extremely ductile elements. The mixture includes high amounts of chromium, nickel, and manganese, whereas the grade includes elements like phosphorus, sulfur, and silicon to provide stability and efficiency to the grade.

These materials are known for providing great welding and pitting properties to the grade. It is also seen that these elements also provide extra resistance reduction, erosion, and rusting.

ASTM A240 S31803 Duplex Steel Plate, Duplex Steel S31803 Plate at Best Price, ASME SA 240 Duplex S31803 Plate, Duplex S31803 Finish Plate, Duplex S31803 Industrial Plate Exporter in India, Duplex S31803 Hot Rolled Plate, 2B Finish Duplex S31803 Plate, SAF S31803 Duplex Steel CR Plates.

ASTM A240 UNS S31803 Plate

Characteristics

  • High resistance to chloride stress corrosion cracking
  • Resistance to chloride pitting and crevice corrosion
  • Good general corrosion resistance
  • Good sulfide stress corrosion resistance
  • High Strength
  • Good weldability and workability

Applications

  • Chemical process vessels, piping and heat exchangers
  • Pulp mill digesters, bleach washers, chip pre-steaming vessels
  • Food processing equipment
  • Oil field piping and heat exchangers
  • Flue gas desulfurization equipment

ASTM A240 UNS S31803 Plate

ASTM A240 UNS S31803 Plate
ASTM A240 UNS S31803 Sheet

ASTM A240 UNS S31803 Sheet
ASTM A240 UNS  S31803 Coil

ASTM A240 UNS S31803 Coil


Standard Specification For Duplex Steel S31803 Plate


Standard : ASTM A240 / ASME SA240

Width : 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc

Thickness : 4mm-100mm

Length : 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc

Surface Finish : 2B, 2D, BA, NO.1, NO.4, NO.8, 8K, hairline, sand blast, Brush, etching, Hot rolled coil (HR), Cold rolled coil (CR), SATIN (Met with Plastic Coated) etc

Hardness : Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc.

Form : Coils, Foils, Rolls, Plain Coil, Shim Coil, Strip, Flats, Blank (Circle), Ring (Flange) etc.


Equivalent Grades - ASTM A240 UNS S31803 Plate

STANDARD
WERKSTOFF NR.
UNS
ASTM A240
1.4462
UNS S31803

Chemical Composition

Grade



C

Mn

Si

P

S

Cr

Mo

Ni

N

UNS S31803

Min

Max

-

0.030

-

2.00

-

1.00

-

0.030

-

0.020

21.0

23.0

2.5

3.5

4.5

6.5

0.08

0.20

Mechanical Properties

Grades Density (g/cm 3) Density (lb/in 3) Melting Point (°C) Melting Point (°F)
S31803 7.805 0.285 1420 – 1465 2588 – 2669

Price List of ASTM A240 UNS S31803 Plates

Grade Price in UAE Dirham Price in US ($)
Duplex UNS S31803 Plate price per kg AED 16-19 UAE Dirham  $ 4 - 5
Duplex UNS S31803 Sheet price per kg AED 16-21 UAE Dirham  $ 4 - 6

Physical Properties

Physical property Value
Density: 0.278 lb/in3
Melting Range:2525-2630°F

Specific Heat Capacity at 212°F

0.119 Btu/lb/°F

Thermal Conductivity at 212°F

8.4 Btu/hr-ft-°F

Poisson's Ratio

0.3

Elastic Modulus at 72°F

29 x 10 psi


Types Of ASTM A240 UNS S31803 Plates:

ASTM A240 UNS S31803 Plate

ASTM A240 UNS S31803 Plate
 Duplex UNS S31803 Plate

Duplex UNS S31803 Plate
SA240 Duplex S31803 Plate

SA240 Duplex S31803 Plate
SA240 Duplex S31803 Plate

Super Duplex Gr.S32760 Plates
 2B Finish Duplex Steel S31803 Plate

2B Finish Duplex Steel S31803 Plate
 Uns S31803 Plate

Uns S31803 Plate


Size Chart

Stocked Sizes
Size (in inches)
Size (in mm)
.125"
3.18mm
.134"
3.40mm
.156"
3.96mm
.187"
4.75mm
.250"
6.35mm
.312"
7.92mm
.375"
9.53mm
.500"
12.7mm
.625"
15.9mm
.750"
19.1mm
.875"
22.2mm
1"
25.4mm
1.125"
28.6mm
1.250"
31.8mm
1.500"
38.1mm
1.750"
44.5mm
2"
50.8mm
2.500"
63.5mm
3"
76.2mm

ASTM A240 UNS S31803 Plate Price List

ASTM A240 UNS S31803 Plate

Price

ASTM A240 31803 SheePlate price $5-$8/kg
Duplex Steel UNS S31803 Plate price 300- 500 Rupee/kg
2B Finish Duplex S31803 Plate price 15-20 Dirham/kg
UNS S31803 Duplex Plates Price 3- 5 pound/kg
SAF 2205 Duplex Plate Price 1-1.9 kuwaiti Dinar/kg

Notes: Prices Are Fluctuating as per Market.
