Duplex Steel 2205 sheet is a nitrogen enhanced duplex stainless steel that was developed to combat common corrosion problems encountered with the 300 series stainless steels. “Duplex” describes a family of stainless steels that are neither fully austenitic, like 304 stainless, nor purely ferritic, like 430 stainless. The structure of 2205 duplex stainless steel consists of austenite pools surrounded by a continuous ferrite phase. In the annealed condition, ASTM A240 Duplex 2205 Sheets contains approximately 40-50% ferrite. Often referred to as the work horse grade 2205 is the most widely used grade in the duplex family of stainless steels.
The advantage of a duplex structure is that it combines the favorable qualities of a ferritic alloy (stress corrosion cracking resistance and high strength) with those of an austenitic alloy (ease of fabrication and corrosion resistance). Usage of Duplex 2205 Sheet should be limited to temperatures below 600° F. Extended elevated temperature exposure can embrittle 2205 stainless.
Duplex Steel UNS S32205 Sheet is a cost effective solution for many applications where the 300 series stainless steels are susceptible to chloride stress corrosion cracking. Stress corrosion cracking occurs when stainless steels are subjected to tensile stress, while in contact with solutions containing chlorides. Increasing temperatures also increase the susceptibility of stainless steels to stress corrosion cracking.
The combination of chromium, molybdenum and nitrogen convey the good resistance of 2205 to chloride pitting and crevice corrosion. This resistance is extremely important for services such as marine environments, brackish water, bleaching operations, closed loop water systems and some food processing applications. The high chromium, molybdenum and nitrogen contents of Duplex 2205 Sheets provide corrosion resistance superior to common stainless steels, such as, 316L and 317L in most environments.
| Standard Industry Specifications |
ASME SA 240, ASTM A 240, UNS S32205, W.NR. 1.4462, GE-S400/ S1000, PWA-LCS, EN 10028-7, RR SABRe Edition 2, DFARS Compliant. |
|---|---|
| Material | Duplex 2205 Sheet &Plate |
| Specification | ASTM A240 / ASME SA240 |
| Standard Sizes | 1000 x 2000 mm, 1220 x 2440 mm, 1500 x 3000 mm, 2000 x 2000 mm, 2000 x 4000 mm |
| Tolerances of Width and thickness |
|
| Width | 10-2500mm |
| SA-240 Duplex 2205 Plate & Sheet Thickness | 0.1mm to 100 mm Thk |
| SA 240 Type 2205 Plate & Sheet Length | 2m, 2.44m, 3m, or as required |
| SA 240 GR 2205 Plate & Sheet Finish | 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated), Cold rolled sheet (CR), Hot rolled plate (HR), No.1 finish hot rolled 2205 Duplex Plate, 2B, 1D, BA, No.4, 8K, hairline, satin, brush, mirror etc. |
| SA 240 TP 2205 Plate & Sheet Hardness | Quarter Hard, Half Hard,Spring Hard, Soft, Hard, Duplex 2205 Sheet suppliers |
| Stock available in form of | Shim Sheet, Rolls, Strip, Flats, Clad Plate, Plain Sheet, Plate, Sheet, Coils, Foils, Rolling Sheet, Rolling Plate, Flat Shim, Flat Sheet, Blank (Circle), soft annealed, sheared, annealed, tread plate,descaled, Checker Plate |
| Profiling |
To provide a full profiling service in India we use numerous profiling methods including:
|
| Plasma profiles | As per customer's drawings |
| Value added services for Duplex 2205 Sheet & Plate | Plasma cutting, Waterjet cutting, Bending and mechanical processing, Laser cutting, welding, edge preparation, sawing and shearing. |
| Value added services for Duplex 2205 Coil |
|
| Why choose Calicometal? |
|
| Specialized in |
|
| Delivery time | Generally it is 7-10 days if the Duplex 2205 Sheet & Plate are in stock. or it is 15-20 days if the Duplex 2205 Plate & Sheet are not in stock, it depends to quantity. |
|
STANDARD
|
WERKSTOFF NR.
|
UNS
|
|---|---|---|
Duplex 2205 Plate |
1.4462 / 1.4462 |
UNS S31803 / UNS S32205 |
|
Grade |
C |
Mn |
Si |
P |
S |
Cr |
Mo |
Ni |
N |
|
|
2205 (S31803) |
Min Max |
- 0.030 |
- 2.00 |
- 1.00 |
- 0.030 |
- 0.020 |
21.0 23.0 |
2.5 3.5 |
4.5 6.5 |
0.08 0.20 |
|
2205 (S32205) |
Min Max |
- 0.030 |
- 2.00 |
- 1.00 |
- 0.030 |
- 0.020 |
22.0 23.0 |
3.0 3.5 |
4.5 6.5 |
0.14 0.20 |
|
Grade |
Tensile Str |
Yield Strength |
Elongation |
Hardness |
|
|
Rockwell C (HR C) |
Brinell (HB) |
||||
|
2205 |
621 |
448 |
25 |
31 max |
293 max |
| Surface finish | Width in Mm | Thickness in MM |
| 2H – Work hardened | 3 To 630 | 0.05 To 1.50 |
| 2H – Work hardened | 1524 max. | 0.4 To 6.35 |
| 2D – heat treated, Cold rolled, pickled | 1524 max. | 0.4 To 6.35 |
| 2R – bright annealed, Cold rolled | 1524 max. | 0.25 To 3.5 |
| Deco | 1524 max. | 0.3 To 3.5 |
| brushed, Polished | 1524 max. | 0.5 To 4.0 |
| 2R – Cold-rolled, bright annealed | 3 To 649 | 0.05–1.50 |
| 2B – Cold rolled, skin passed, heat treated, pickled | 2032 max. | 0.25 To 8.0 |
| 1D – Hot rolled, pickled, heat treated | 2032 max. | 2.4 To 12.7 |
| 2E – Cold rolled, mechanically descaled, heat treated | 2032 max. | 0.4 To 8.0 |
| ASTM A240 Duplex 2205 Checkered sheet | ASTM A240 Duplex 2205 Polished sheet |
| ASTM A240 Duplex 2205 3/4 Hard sheet | Duplex 2205 Quarter Hard sheet |
| Duplex Steel F51/F60 HR(Hot Rolled) sheet | UNS S32205 Quarter Hard sheet |
| ASTM A240 Duplex 2205 1/2 Hard sheet | ASTM A240 Duplex 2205 Quarter Hard sheet |
| Werkstoff Nr. 1.4462 Galvanized sheet | Duplex 2205 3/4 Hard sheet |
| Werkstoff Nr. 1.4462 1/4 Hard sheet | Werkstoff Nr. 1.4462 Full Hard sheet |
| Duplex Steel F51/F60 Galvanized sheet | UNS S32205 Galvanized sheet |
| Duplex Steel F51/F60 Polished sheet | ASTM A240 Duplex 2205 Galvanized sheet |
| Duplex 2205 1/4 Hard sheet | UNS S32205 Polished sheet |
| Duplex 2205 Full Hard sheet | Werkstoff Nr. 1.4462 HR(Hot Rolled) sheet |
| ASTM A240 Duplex 2205 1/4 Hard sheet | UNS S32205 Full Hard sheet |
| Duplex Steel F51/F60 CR (Cold Rolled) sheet | Duplex 2205 1/2 Hard sheet |
| UNS S32205 CR (Cold Rolled) sheet | US $1,575.00 - $5,250.00 / Ton | Designed for use in boilers and pressure vessels under extreme conditions. |
| UNS S32205 1/4 Hard sheet | US $840.00 - $3,150.00 / Ton | Hot deal – available in a range of thicknesses for different industries. |
| Werkstoff Nr. 1.4462 Polished sheet | US $1,050.00 - $6,090.00 / Metric Ton | Suitable for both light and heavy-duty applications. |
| Duplex Steel F51/F60 Checkered sheet | US $1,575.00 - $2,625.00 / Ton | Perfect for aesthetic applications with a polished, sleek surface. |
| Werkstoff Nr. 1.4462 Quarter Hard sheet | US $1,050.00 - $3,570.00 / Metric Ton | Excellent for pressure vessels, heat exchangers, and other industrial uses. |
| UNS S32205 Checkered sheet | US $1.05 - $2.94 / Kilogram | Ideal for the shipbuilding industry with exceptional resilience. |
| Werkstoff Nr. 1.4462 1/2 Hard sheet | US $1,890.00 - $2,100.00 / Metric Ton | Excellent for intricate machining and fine finishes. |
| UNS S32205 1/2 Hard sheet | US $2.10 - $5.25 / Kilogram | Reliable for welding and forming applications. |
| ASTM A240 Duplex 2205 CR (Cold Rolled) sheet | US $1,050.00 - $2,625.00 / Ton | Lightweight but strong – perfect for precise and delicate applications. |
| Duplex Steel F51/F60 1/4 Hard sheet | US $1,050.00 - $3,675.00 / Metric Ton | Designed for high-stress, high-temperature applications. |
| Duplex 2205 Polished sheet | US $2,992.50 - $3,150.00 / Ton | High-performance material for critical infrastructure. |
| Duplex Steel F51/F60 Full Hard sheet | US $2.63 - $10.50 / Kilogram | Versatile, corrosion-resistant, and perfect for a variety of projects. |
| Duplex Steel F51/F60 Half Hard sheet | US $2.10 - $5.25 / Kilogram | Strong, reliable, and available in various thicknesses for tailored use. |
| Duplex 2205 HR(Hot Rolled) sheet | US $4,200.00 - $4,515.00 / Metric Ton | Durable, high-quality material for long-term heavy-duty usage. |
| Duplex 2205 Half Hard sheet | US $1,050.00 - $3,150.00 / Ton | Heavy-duty plates built for challenging construction tasks. |
| Duplex Steel F51/F60 Quarter Hard sheet | US $2,624.00 - $2,729.00 / Ton | High-strength, ideal for structural integrity in demanding environments. |
| UNS S32205 Half Hard sheet | US $1,050.00 - $2,625.00 / Ton | Ideal for industrial applications requiring strength & durability. |
| Duplex 2205 Galvanized sheet | US $840.00 - $5,124.00 / Ton | Prized for corrosion resistance and toughness in extreme conditions. |
| Duplex 2205 Checkered sheet | US $933,332.40 / Piece | Custom, specialized plates made to order for unique projects. |
| UNS S32205 HR(Hot Rolled) sheet | US $4,200.00 - $4,725.00 / Metric Ton | Premium grade for superior mechanical properties. |
|
Products
|
Price (Per Kg)
|
Product |
Price (Per Kg) |
2205 Duplex Stainless Steel Plate |
₹ 300/ Kg |
Stainless Steel 2205 Plate |
₹ 250/ kg |
2205 Duplex Stainless Steel Plate |
₹ 300/ Kg |
Ss S32550 Super Duplex Steel Plate |
₹ 200/ Kg |
Stainless Steel Duplex 2205 Sheet |
₹ 150/ Kg |
UNS S31803 Sheets |
₹ 300/ Kg |
Notes: Prices Are Fluctuating as per Market
